1: Product Name: Airtac TR TN series Twin-rod cylinder TN 25x30S double acting type
2: Order Code
Note:
1) TN series are alll with magnet
2) When the thread is standard, the code is blank
3: Specification | Bore size(mm) | 10 | 16 | 20 | 25 | 32 |
| Acting type | Double acting |
| Fluid | Air (to be filtered by 40 um filter element) |
| Operating pressure | 0.1~1.0MPa(15~145psi)(1.0~10.0bar) |
| Proof pressure | 1.5MPa(215psi)(15bar) |
| Temperature °c | -20~70 |
| Speed range mm/s | 30~500 |
| Adjustable stroke mm | -10~0 |
| Cushion type | Bumper |
| Non-rotating tolerance | ±0.4° | ±0.3° |
| Port size | M5x0.8 | 1/8" |
4: Product Features 1.Enterprises standard is implemented.
2.Embeded installation and fixation mode saves the installation space.
3.It is good resistance to bending and twisting moments.
4. Mounting holes on three sides facilitates multi-position mounting.
5.Bumper in front of the barrel can adjust the stroke of cylinder and relieve impact.
6.Standard configuration of this series has magnet and the type without magnet is not available.
5: Installation Usage 1.When load changes in the work, the cylinder with abundant output capacity shall be ed.
2.Relative cylinder with high temperature resistance or corrosion resistance shall be chosen under the condition of high temperature or corrosion.
3.Necessary protection measure shall be taken in the environment with higher humidity, much dust or water drops, oil dust and welding dregs.
4.Dirty substances in the pipe must be eliminated before cylinder is connected with pipeline to prevent the entrance of particles into the cylinder.
5.The medium used by cylinder shall be filtered to 40μm or below.
6.As both the front cover and piston are short, too large stroke can not be ed.
7.Anti-freezing measure shall be adopted under low temperature environment to prevent moisture freezing.
8.The cylinder shall avoid redial load in operation to maintain the normal and extend service life.
9.If the cylinder is dismantled and stored for a long time, please conduct anti-rust treatment to the surface. Anti-dust cap shall be ed into the inlet and outlet ports. As the precision of the manufacture and guide is high, Please do not dismantle the fixed block or cylinder cover.
6: Material of major parts 7: Structures and Dimension 1. Φ10
2. Φ16~Φ25
3: Φ32
7: Products Shopping Guide For example: you want to purchase a batch of cylinders but you don't know which type you are really want, so you can tell me all your requirement and I'll recommend to you.
8: Samples You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.
9: After-sale Service We can provide a series of after-sale service, such as product introduction, mounting, debugging, technical support and so on.
