1. Product name: BR2000 Airtac Pneumatic Components Air source 1/4 inch AR series precision control unit Aluminum Regulator
2. Specification
| Model | AR1500 | AR2000 | BR2000 | BR3000 | BR4000 |
| Fluid | Air | ||||
| Port size | 1/8" | 1/4" | 1/4" | 3/8" | 1/2" |
| Pressure range | 0.05~0.9MPa(7~130Psi) | ||||
| Max. pressure | 1.0MPa(145Psi) | ||||
| Proof pressure | 1.5MPa(215Psi) | ||||
| Temperature range | ﹣20~70℃ | ||||
| Weight | 200g | 230g | |||
3. Other products
| Filter | Regulator | Lubricator | Filter Regulator | FR.L unit | F.R.L unit |
| AF1500 | AR1500 | AL1500 | AFR1500 | AFC1500 | AC1500 |
| AF2000 | AR2000 | AL2000 | AFR2000 | AFC2000 | AC2000 |
| BF2000 | BR2000 | BL2000 | BFR2000 | BFC2000 | BC2000 |
| BF3000 | BR3000 | BL3000 | BFR3000 | BFC3000 | BC3000 |
| BF4000 | BR4000 | BL4000 | BFR4000 | BFC4000 | BC4000 |
4. Order code
5. Samples
You can send a sample to customize the products, we have many engineers can help it; If you want a product of mine, but you are not sure if it's what you want, so you can ask for a sample from me, it will be free.
6. Product show
7. Inner structure
| NO. | Item | Material |
| 1 | Push button | POM |
| 2 | Adjusting button | POM |
| 3 | Adjusting nut | Steel |
| 4 | Adjusting pillar | Steel |
| 5 | Adjust spring | SWC |
| 6 | Fixed ring | POM |
| 7 | Adjusting seat | POM |
| 8 | Body | Aluminum alloy |
| 9 | Diaphragm | SUS304 & rubber |
| 10 | Needle O-ring | NBR |
| 11 | Balance needle | POM |
| 12 | Needle gasket | Aluminum alloy & rubber |
| 13 | Cap O-ring | NBR |
| 14 | Return spring | Stainless steel |
| 15 | Regulator cap | POM |
8. Product feature
1. The structure is delicate and compact, which is convenient for installation and application.
2. The pressed-in self-locking mechanism can prevent the abnormal movement of the set pressure caused by external interfere.
3. In addition to standard type, lower pressure type is optional (The highest adjustable pressure is 0. 4MPa).
9. Drawing
