K0331
Goyen
1. Product name: K0331 K331 100/120V 50/60Hz Pulse Valve Goyen RCA3D2 RCA3D0 Screws/spade terminals, QT2 Solenoid Coil
2. Operation:
Recommended on time range: 50-500ms
Recommended time between pulses: 1 minute or greater.
3. Installation:
Slide solenoid over ferrule tube. Ensure terminals are on top. For QT and QF type solenoids ensure nylon washer is in place. Slide clip onto pilot iron top. Ensure voltage supplied to solenoid is within -10% and +15% of the solenoid rated voltage.
4. Suitable for:
All integrally piloted Goyen dust collector diaphragm valves, RCA3D series pilot valves and pilot valve enclosures, and 3DS pilot valves.
5. Approvals:
• C-Tick
• EMC (89/336/CE)
6. Construction:
Encapsulation: PA-6
C-frame: Mild steel zinc passivated
Bobbin: PA-6
Insulation class: B/130°C
Rating: Non-continuous use only
Clip: Mild steel (mechanically plated)
7. Drawing:
8. Product show:
